3 Axle Side Dump Tipper Semi Trailer
3 Axle Side Dump Tipper Semi Trailer
3 Axle Side Dump Tipper Semi Trailer
3 Axle Side Dump Tipper Semi Trailer

3 Axle Side Dump Tipper Semi Trailer

The carrying capacity of side tipper dump trailer ranges from 20 tons to 180 tons, depending on your actual transportation needs. The 3 axle side tipper dump trailer we provide has a capacity of 20 cubic meters, 30 cubic meters, and 45 cubic meters, and can carry goods of 40 tons, 50 tons, 60 tons, 70 tons, 80 tons, and even 100 tons. For larger load demands, 4-axle and 5-axle dump semi trailers can carry goods ranging from 100 to 120 tons. If you have higher load-bearing requirements, our factory also offers a multi axle side tipper dump trailer option. We have a professional team of engineers with a deep understanding of the complex road conditions in Africa, who can customize and design the most suitable dump trailer according to your specific transportation needs.

Specification

The 3 axle side tipper semi trailer is mainly used to transport those with large but low hardness. This 3 axle side tipper semi trailer is equipped with six lifting liquid pressure cylinders and a shift hydraulic cylinder under the fighting body. The six hydraulic cylinders are used to improve and decrease operations. The empty space was buried. Its professional design of 3 axle side tipper semi trailer can meet your various transportation needs.For dumping trailers, key components include plate spring suspension and heavy car shafts. These components of 3 axle side tipper semi trailer ensure the stability and load-bearing capacity of the 3 axle side tipper semi trailer under complex road conditions.In addition, the details such as tires, side guards and landing gear are also an important part of our 3 axle side tipper semi trailer. We also choose high -quality accessories from well -known brands to ensure the performance and reliability of the vehicle.


Product NameSide Dump Semi Trailer
Outside Dimension(L*W*H)(mm)10000-14000*2550*2900mm (customizable)
Max Loading Capacity (kg)30000-100000 (customizable)
Tare Weight7-9 Tons
Main BeamQ345B manganese plates, automaticsubmerged arc welded

Upper:16mm, Lower:16mm, Mid web:8mm

The height of beam:500mm,
FloorSteel sheet 4mm thickness or diamond plate
Tyre Specifications11.00R20/12R22.5
Rim8.0/9.0*12/16 pieces
Axle13 Tons Fuwa / BPW/JOZOTG/Other
Leaf-spring90mm*13/16mm*10 pieces
SuspensionMechanical/ Air suspension
King Pin#50(2")/#90(3.5"), JOST/Other Brand
Landing Gear28000 kg,JOST
Spare Wheel CarrierOne set of spare wheel carrier
Electrical System24V, 7core socket, lights according toEuropean standards.
Tool BoxSteel/aluminum(1+0.5m)
