The lowboy gooseneck trailers can carry very heavy goods, such as heavy machinery and equipment, large building components, etc.

The design of the lowboy gooseneck trailer semi trailer makes the loading position of the cargo lower, which reduces the focus of the cargo and increases the stability in the transportation process.

The lowboy gooseneck trailers can adapt to various complex road conditions and terrain, such as mountainous areas and urban streets.

The goose neck design of the lowboy semi trailer for sale provides greater flexibility, making it easier for vehicles to operate in turning and narrow spaces.

Specification

lowboy equipment trailers are designed with low tablets, that is, the platform is low in height from the ground, usually lower than ordinary lowboy equipment trailers. Our lowboy equipment trailers can reduce the focus of the cargo and improve the stability and safety of the transportation process. The flat plate design of the lowboy semi trailer for sale is convenient for the use of cranes or other lifting equipment for loading and unloading operations, reducing the loading and unloading time and cost. Lowboy semi trailer for sale is made of high-strength materials, such as special steel or aluminum alloy to ensure that the vehicle structure is strong and durable.

Dimension12500mm*2500mm*3050mm(1500mm sidewall high)
Load Capacity(T)≤60T
Axle3 axles, 13T/16T, FUWA/BPW brand
Tire12 units, 12.00R22.5/315 80R22.5(Specially designed and for oversea markets)
SuspensionMechanical suspension,bogie suspension or air suspension(Specially designed for oversea markets)
King pinJOST brand 2.0 or 3.5inch(bolted or welded type)
Landing gearJOST brand
Main beamHeight: 500mm Upper Plate: 14mm Middle Plate: 8mm
Side beam16mm or 18mm steel channel(material: Q235steel)
Bottom Platform3mm-thick checkered plate
Brake chamberWABCO RE 6 relay valve: T30/30+T30 Spring brake chamber(TKL brand): 45L air tanks
ABSOptional
ValveWABCO valve
Tool box1m*0.5m*0.5m(The tool box contains 1 tire spanner, 1 gudgeon sleeve and 1 cranking bar. Its size can be tailored to suit your needs)
